Medical Displays: Precision and Reliability is our Focus

You are here

OLED Products

Picture Size Part Number Panel Size Resolution Color Thickness Bonding IC Interface Connection Method Datasheet
0.49" USMP-P005-064032WBI-A0 14.5 x 11.6 64 x 32 W 1.02 COG SSD1306ZBZ I2C Hot Bar link to datasheet
0.7" USMP-P007-096016WBI-A0 24 x 7.44 96 x 16 W 1.02 COG LD7054 Parallel, SPI, I2C Connector link to datasheet
0.7" USMP-P32401 24 x 7.44 96 x 16 W 1.02 COG LD7054 Parallel, SPI, I2C Connector link to datasheet
0.8" USMP-P008-096032WBI-A0 28.5 x 11.5 96 x 32 W 1.22 COG SSD1307 SPI, I2C Hot Bar link to datasheet
0.91" USMP-P010-128032WBI-A0 30 x 11.5 128 x 32 W 1.02 COG SSD1307 SPI, I2C Connector link to datasheet
0.96" USMP-P010-128064WBI-C0 26.7 x 19.26 128 x 64 W 1.22 COG SSD1306ZBZ Parallel, SPI, I2C Hot Bar link to datasheet
0.96" USMP-P25317 26.7 x 19.26 128 x 64 W 1.22 COG SSD1306ZBZ Parallel, SPI, I2C Hot Bar link to datasheet
1.1" USMP-P19601 29 x 21 96 x 64 Y 1.61 TAB SSD1325 Parallel, SPI Hot Bar link to datasheet
1.27" USMP-P013-052160MBI-A0 14 x 38.5 52 x 160 262k 1.02 COG SSD1357Z SPI Connector link to datasheet
1.29" USMP-P013-128096LBI-A0 33 x 25.8 128 x 96 65k, 262k 1.02 COF SSD1351UR1 Parallel, SPI Hot Bar link to datasheet
1.32" USMP-P013-128096WBI-A0 32.5 x 29.2 128 x 96 W 1.42 COG SSD1307 Parallel, SPI, I2C Hot Bar link to datasheet
1.46" USMP-P015-128128LBI-B0 33.5 x 33.5 128 x 128 65k, 262k 1.42 COF SSD1351 Parallel, SPI Connector link to datasheet
1.5" USMP-P015-128128WBI-A0 33.8 x 36.5 128 x 128 W 1.22 COG SSD1327 Parallel, SPI, I2C Hot Bar link to datasheet
1.6" USMP-P016-128064YBI-A0 41.9 x 28 128 x 64 Y 1.42 COF SSD1325 Parallel, SPI Connector link to datasheet
1.8" USMP-P018-160128LBI-A0 42.7 x 33.4 160 x 128 65k, 262k 1.85 COF SSD1353 Parallel, SPI Hot Bar link to datasheet
2.4" USMP-P024-128022YBI-A0 63.3 x 20.8 128 x 22 Y 1.42 COG SSD1305 Parallel, SPI, I2C Hot Bar link to datasheet
2.4" USMP-P024-128064WBI-B0 60.5 x 37 128 x 64 W 1.82 COG SSD0301 Parallel, SPI, I2C Connector link to datasheet
3.2" USMP-P032-256064YBI-A0 87.4 x 28.5 256 x 64 Y 1.82 COF SSD1322 Parallel, SPI Connector link to datasheet

TFT Products

Diagonal Size Resolution Part Number Interface Active Area Viewing Angle Contrast Ratio Brightness Operating Temp. Touch Panel Datasheet
1.1" 132*132 USMP-T011-013013MDV-A0 MIPI-SPI 19.1268 x 19.1268 85 / 85 / 85 / 85 800 1000 -30°~80° No link to datasheet
1.26" 320*320 USMP-T013-032032NDH-A0 MIPI-SPI 31.968 × 31.968 55 / 80 / 45 / 55 150 300 -20°~70° No link to datasheet
1.38" 220*220 USMP-T014-022022NDH-A0 MCU 35.10 x 35.10 80 / 55 / 80 / 80 700 340 -20°~70° No link to datasheet
1.77" 128*160 USMP-T018-012016NAS-A0 8-bit 28.032 x 35.04 45 / 15 / 45 / 45 150~200 290 -20º~70º No link to datasheet
2.2" 240*320 USMP-T022-024032NCJ-A0 MPU 38.48 x 44.64 80 / 80 / 80 / 80 300~700 400 -20º~70º No link to datasheet
2.4" 240*320 USMP-T024-024032MEG-A1 RGB 36.72 x 48.96 90 / 90 / 90 / 90 500 400 -20~70° No link to datasheet
2.4" 240*320 USMP-LPS-T024-024032MFW-B0 MCU 80 / 80 / 80 / 80 1200 350 -20~70° Yes link to datasheet
2.47" 480*480 USMP-T025-480x480-19100360 MIPI-SPI 62.64 x 62.64 85 / 85 / 85 / 85 1000 400 -10°~60° No link to datasheet
2.95" 432*432 USMP-T030-432432NAV-A0 Digital 24-bits RGB 74.39 x 74.39 80 / 80 / 80 / 80 800 1000 -30º~85º No link to datasheet
2.95" 432*432 USMP-T030-043043NAV-B0 Serial RGB 74.39 x 74.39 80 / 80 / 80 / 80 800 1000 -30°~85° No link to datasheet
3.0" 432*432 USMP-T030-043043CAV-A0 RGB 74.39 x 74.39 80 / 80 / 80 / 80 800 850 -30°~85° Yes link to datasheet
3.5" 320*240 USMP-T035-032024NAS-A0 Digital 24-bits RGB 70.08 x 52.56 45 / 50 / 50 / 50 200~250 280 -20º~70º No link to datasheet
3.5" 240*320 USMP-T035-024032NDU-A0 C-MOS 50 pins 53.28 x 71.04 85 / 85 / 85 / 85 900 600 -30º~85º No link to datasheet
4.21" 680*680 USMP-T042-680680NAV-A0 RGB 106.68 x 106.68 80 / 80 / 80 / 80 1000 -20°~70° No link to datasheet
4.3" 480*272 USMP-T043-048027NAS-A0 Digital 24-bits RGB 96.7 x 55.3 60 / 60 / 60 / 60 600 460 -20º~70º No link to datasheet
5" 800*480 USMP-LPS-T050-080048MFD-A0 RGB 80 / 80 / 80 / 80 1000 800 -30~80° Yes link to datasheet
5" 800*480 USMP-T050-080048NDU-A0 C-MOS 40 pins 108 x 64.8 60 / 70 / 70 / 70 600 1000 -30º~80º No link to datasheet
5.7" 320*240 USMP-T057-032024NAF-A0 RGB 115.20 x 86.4 50 / 65 / 65 / 65 450 1200 -20°~70° No link to datasheet
5.7" 320*240 USMP-T057-032024NDU-A0 RGB 115.2 x 86.4 80 / 60 / 80 / 80 800 800 -20°~70° No link to datasheet
5.7" 640*480 USMP-T057-064048NBQ-A0 1 ch TTL 115.2 x 86.4 70 / 70 / 80 / 80 800 450 -20°~85° No link to datasheet
5.7" 640*480 USMP-T057-064048NCJ-A0 1 ch TTL 115.2 x 86.4 65 / 65 / 75 / 75 600 500 -30°~85° No link to datasheet
5.7" 640*480 USMP-T057-064048NAV-A0 RGB 115.2 x 86.4 60 / 40 / 70 / 70 300 900 -20°~70° No link to datasheet
5.7" 320*240 USMP-T057-032024NAV-A0 RGB 115.2 x 86.4 50 / 70 / 70 / 70 490 350 -20°~70° No link to datasheet
6.5" 640*480 USMP-T065-064048NDN-A0 1 ch LVDS 132.48 x 99.36 80 / 80 / 70 / 70 600 700 -30º~85º No link to datasheet
7" 1280*768 USMP-LPS-T070-128076MFW-A0 LVDS 80 / 80 / 80 / 80 1400 1300 -30~80° Yes link to datasheet
7" 800*480 USMP-T070-080048CCJ-A0 6bit LVDS 152.4 x 91.44 65 / 65 / 70 / 70 400 850 -20°~70° PCap link to datasheet
7" 800*480 USMP-T070-080048NDN-A0 1 ch LVDS 8 bit 152.4 x 91.44 80 / 80 / 60 / 80 500 400 -30º~85º No link to datasheet
7" 800*480 USMP-VC070WV-03L-TP-2 6bit LVDS 152.4 x 91.44 65 / 65 / 70 / 70 300 850 -20°~70° PCap link to datasheet
7" 800*480 USMP-T070-080048NDU-A0 20-pin LVDS 152.4 x 91.44 85 / 85 / 85 / 85 600 450 -30º~80º No link to datasheet
7" 800*480 USMP-T070-080048NAV-A0 RGB 152.4 x 91.44 80 / 80 / 80 / 80 600 500 -20º~70º No link to datasheet
7" 800*480 USMP-T070-080048NDU-B0 20-pin LVDS 152.4 x 91.44 85 / 85 / 85 / 85 1000 800 -40º~85º No link to datasheet
7" 800*480 USMP-T070-080048CAV-A0 LVDS 152.4 x 91.44 65 / 65 / 70 / 70 400 850 -30°~80° Yes link to datasheet
7" 1920*1080 USMP-T070-192108NDU-A0 20-pin LVDS 169 x 104 x 10 85 / 85 / 85 / 85 800 700 -20º~70º No link to datasheet
7" 800*480 USMP-T070-080048RCJ-A0 RGB 152.4 x 91.44 60 / 60 / 70 / 70 400 400 -20º~70º Yes link to datasheet
8" 1024*600 USMP-T080-102060NBQ-A0 LVDS 176.6 × 99.36 85 / 85 / 85 / 85 1000 750 -30º~85º No link to datasheet
8" 800*600 USMP-T080-080060NDU-A0 LVDS 174 x 104.4 60 / 80 / 80 / 80 800 1500 -30º~80º No link to datasheet
8.4" 800*600 USMP-T084-080060NDN-A0 1 ch LVDS 8 bit 170.4 x 127.8 80 / 80 / 80 / 60 600 450 -30º~85º No link to datasheet
10.1" 1280*800 USMP-LPS-T101-128080MFD-A0 MIPI-SPI 80 / 80 / 80 / 80 1000 1000 -30~80° Yes link to datasheet
10.1" 1024*600 USMP-T101-102060NAS-A0 LVDS 222.72 x 125.28 80 / 80 / 80 / 80 500 500 -30º~85º No link to datasheet
10.1" 1280*1200 USMP-T101-192120NDU-A0 LVDS 217.44 x 135.9 85 / 85 / 85 / 85 800 800 -30º~85º No link to datasheet
10.4" 640*480 USMP-T104-064048NDN-A0 1 ch TTL 211.2 x 158.4 80 / 80 / 60 / 70 700 400 -20º~80º No link to datasheet
10.4" 800*600 USMP-T104-080060NDU-A0 20-pin LVDS 211.2 x 158.4 60 / 80 / 80 / 80 800 1500 -30º~80º No link to datasheet
10.4" 800*600 USMP-T104-080060NCJ-A0 6bit LVDS 211.2 x 158.4 70 / 70 / 50 / 60 500 500 -30º~80º No link to datasheet
10.4" 1024*768 USMP-T104-102076NDU-A0 20-pin LVDS 211.2 x 158.4 60 / 70 / 75 / 75 800 1200 -20º~70º No link to datasheet
12.1" 800*600 USMP-T121-010076NAF-A0 LVDS 245.76 x 184.32 70 / 70 / 80 / 80 700 600 -30º~80º No link to datasheet
12.1" 800*600 USMP-T121-080060NDN-A0 8-bit 246 x 184.5 80 / 80 / 65 / 75 700 450 -30º~85º No link to datasheet
12.3" 1920*720 USMP-T123-192072NBQ-A0 LVDS 292.608 x 109.728 85 / 85 / 85 / 85 1000 750 -30 ~ 85° No link to datasheet
12.3" 1920*720 USMP-T123-192072NDV-A0 LVDS 292.023 x 109.512 85 / 85 / 85 / 85 1000 700 -30 ~ 80° No link to datasheet
12.3" 1920*720 USMP-T123-192072CDV-A2 LVDS 292.032 x 109.512 85 / 85 / 85 / 85 1000 1000 -30°~80° CTP link to datasheet
19" 1280*1024 USMP-T190-128102NDN-A0 2 ch LVDS 376.32 x 301.056 89 / 89 / 89 / 89 2000 600 0 ~ 50° No link to datasheet
22" 1680*1050 USMP-T220-168105NDN-A0 2 ch LVDS 473.76 x 296.1 89 / 89 / 89 / 89 2000 250 0º~50º No link to datasheet
23" 1920 x 1080 USMP-M230HGE-P20 2 ch LVDS 509.184 x 286.416 85 / 85 / 85 / 85 1000 0°~50° No link to datasheet
27" 1920*1080 USMP-T27-192108MEH-TBD VGA/DVI-D/HDMI 597.6 x 336.15 89 / 89 / 89 / 89 1000 1700 -30º~80º Yes link to datasheet
28" 3480*2160 USMP-T280-384216NBQ-A0 51 pins 8 lane –V by 1 620.93 x 341.28 80 / 80 / 85 / 85 1000 300 0º~50º No link to datasheet
50" 3840*2160 USMP-T500-384216NBQ-A0 8 lane V by 1 1095.84 x 616.41 88 / 88 / 88 / 88 4000 500 0º~50º No link to datasheet

Open Frame Monitor Products

Panel Size Part Number Resolution Active Size Brightness Display Colors Operating Temp. Pixel Pitch Viewing Angle Datasheet
7" USMP-F070-102060RBZ-A0 1024 x 600 156.6 x 90 400 16.7M -30º~85º 0.150 x 0.150 75º / 75º / 75º / 75º link to datasheet
9.7" USMP-F097-102076CBZ-A0 1024 x 768 196.61 x 147.46 260 16.2M 0º~50º 0.192 x 0.192 85º / 85º / 85º / 85º link to datasheet
10.1" USMP-F101-128080CBZ-A0 1280 x 800 216.96 x 135.60 300 16.2M -20º~60º 0.1695 x 0.1695 85º / 85º / 85º / 85º link to datasheet
10.4" USMP-F104-102076CBZ-A0 1024 x 768 211.2 x 158.4 350 16.7M/262K 0º~50º 0.2055 x 0.2055 85º / 85º / 85º / 85º link to datasheet
12.1" USMP-F121-102076CBZ-A0 1024 x 768 245.76 x 184.32 350 16.7M -20º~70º 0.24 x 0.24 80º / 80º / 80º / 80º link to datasheet
14" USMP-F140-192108CBZ-B0 1920 x 1080 309.312 x 173.988 250 262k 0º~50º 0.1611 x 0.1611 85º / 85º / 85º / 85º link to datasheet
14" USMP-F140-192108CBZ-A0 1920 x 1080 309.312 x 173.988 250 262K 0º~50º 0.264 x 0.264 85º / 85º / 85º / 85º link to datasheet
15" USMP-F150-102076CBZ-A0 1024 x 768 304.128 x 228.096 250 16.2M/262k -20º~70º 0.297 x 0.297 80º / 80º / 70º / 70º link to datasheet
15" USMP-F150-102076RBZ-A0 1024 x 768 304.128 x 228.096 300 16.2M/262k -10º~70º 0.297 x 0.297 89º / 89º / 89º / 89º link to datasheet
15" USMP-F150-102076RBZ-B0 1024 x 768 304.128 x 228.096 250 262k -10º~70º 0.297 x 0.297 50º / 50º / 60º / 60º link to datasheet
15.6" USMP-F156-192108CBZ-A0 1920 x 1080 344.16 x 193.59 350 16.7M -10º~70º 0.17925 x 0.17925 60º / 60º / 70º / 70º link to datasheet
17" USMP-F170-128102RBZ-A0 1280 x 1084 337.92 x 270.33 250 16.7M 0º~70º 0.24 x 0.24 80º / 80º / 85º / 85º link to datasheet
17" USMP-F170-128102CBZ-A0 1280 x 1024 337.920 x 270.336 250 16.7M -20º~60º 0.264 x 0.264 85º / 85º / 80º / 80º link to datasheet
17" USMP-F170-128102CBZ-B0 1280 x 1024 337.920 x 270.336 350 16.7M -20º~60º 0.264 x 0.264 85º / 85º / 80º / 80º link to datasheet
17" USMP-F170-128102CBZ-C0 1280 x 1024 337.920 x 270.336 350 16.7M -0º~50º 0.264 x 0.264 85º / 85º / 80º / 80º link to datasheet
18.5" USMP-OFIA185-W-01C 1366 x 768 409.8 x 230.4 250 16.7M 0°~50° 0.3 x 0.3 85º / 85º / 80º / 80º link to datasheet
18.5" USMP-OFIA185-W-01B 1366 x 768 409.8 x 230.4 250 16.7M 0°~50° 0.3 x 0.3 85º / 85º / 80º / 80º link to datasheet
18.5" USMP-F185-192108CBZ-A0 1920 x 1080 408.96 x 230.04 350 16.7M -20º~70º 0.213 x 0.213 89º / 89º / 89º / 89º link to datasheet
19" USMP-F190-128102CBZ-A0 1280 x 1024 376.32 x 301.06 250 16.7M -20º~50º 0.264 x 0.264 85º / 85º / 80º / 80º link to datasheet
21.5" USMP-F215-192108CBZ-A0 1920 x 1080 476.64 x 268.116 250 16.7M 0º~50º 0.24825 x 0.24825 89º / 89º / 89º / 89º link to datasheet
21.5" USMP-F215-192108CBZ-C0 1920 x 1080 476.064 x 267.786 450 16.7M 0º~50º 0.24795 x 0.24795 89º / 89º / 89º / 89º link to datasheet
21.5" USMP-F215-192108CBZ-B0 1920 x 1080 476.64 x 268.116 250 16.7M 0º~50º 0.24825 x 0.24825 89º / 89º / 89º / 89º link to datasheet
21.5" USMP-F215-192108CBZ-D0 1920 x 1080 476.064 x 267.786 250 16.7M 0º~50º 0.24825 x 0.24825 89º / 89º / 89º / 89º link to datasheet
31.5" USMP-F315-192108CBZ-A0 1920 x 1080 698.4 x 392.85 300 16.7M 0º~50º 0.12125 x 0.12125 89º / 89º / 89º / 89º link to datasheet
32" USMP-F320-192108CBZ-A0 1920 x 1080 698.4 x 392.85 300 16.7M 0º~50º 0.12125 x 0.12125 89º / 89º / 89º / 89º link to datasheet
43" USMP-F430-192108CBZ-A0 1920 x 1080 AMG-43IPAM01T1-en 300 16.7M 0º~50º 89º / 89º / 89º / 89º link to datasheet

The environment for displays for medical applications is very rigorous and demanding. Characteristics of a superior display in surgery centers vary quite significantly from those used in an office. US Micro Products offers an array of displays and customizations specifically designed for a variety of uses by surgeons, cardiologists, radiologists, and orthopedists, to name a few. Of particular importance today are archiving and retrieval systems for images and medical records (PACS).

From 2013 to 2017 surgical and clinical review display revenues are each expected to grow at a 9% annually, and diagnostic displays are set to increase by 5%. This is according to a report last year from NPD Display Search. The report also states that, “Technology continues to advance at a rapid pace, creating new medical imaging procedures that require sophisticated high resolution and larger display solutions,” Important growth areas are in diagnostics (half of all display users), surgery (a quarter of all users), and in radiology. Another report from the marketing firm  IHS says the world-wide market for medical displays will be $3.2 billion in revenue in 2017, up from $2.5 billion in 2012.

We offer medical display solutions that provide reliability, readability and safety. Our displays are designed to be useful and reliable in low/diffused-light conditions and in situations where contamination from touching, smears, spills and spatters is likely. The space around an operating table is at a premium and not everybody who needs it can have a close and unobstructed view. Our engineers have taken this into account and have designed displays to be viewable from wide angles and with higher resolution so fine details won’t be missed.

Where to Start?

Our displays designed for medical applications offer a range of affordable choices for customers with specific needs:


High Resolution Displays 2M pixel up to 5M pixel
High Contrast and High Brightness High contrast ratio to help resolve fine detail, contrast ratio from 600:1 to 1000:1
  Brightness can be customized according to customer’s application from 250nits to 500nits or higher
Wide view angles LCD In-Plane Switching technology (IPS) to enhance viewing angle without color shift or decrease of image quality
  Displays are available with a minimum of 80 degrees viewability in each direction
High Color Gamut to provide True Color 10 bits to 12 bits of color according to customer’s system configuration
AG/AR anti-reflective, evaporative coated cover glass and optical bonding to enhance readability
Ethanol agent-durable cover glass to protect display and make easy to clean
Friendly DVI connection interface. Display port can be customized.
Long lifetime of at least three years under continuous use.
50K hours of backlight life
Projected Capacitive Touchscreen technology (PCAP) Able to detect touches by an operator wearing latex gloves and if there are fluids or blood on the screen
Low power consumption for battery powered portable devices
Extended battery life due to low power backlights and displays. Design-in smallest and lightest display and backlight for weight consideration
Specialized displays for professional wearables
APPLICATIONS

TFT for Ultrasound Control Panel

Our TFTs have the high quality and long life support to meet specific medical requirements.

Portable Medical Device LCD

We have designed in displays for many portable medical devices. In each application, we take into consideration the power usage, backlighting requirements and information that needs to be displayed. By using low power backlights and displays, we are able to extend the battery life of the product. We also design in the smallest and lightest display and backlight for weight consideration. Many applications use a segment display utilizing custom icons and a numeric readout. Others require a graphic display in order to display a variety of information.

Ultrasound Imaging LCD

A standard two-line character display with backlight provides information to the operator what mode the machine is operating in.


In every respect US Micro Products' displays for medical applications are the right answer for your system. Our engineers design industry-standard products that conform to standards of practice around the world. Our reliability, readability and cost value are second-to-none in the industry. Our Display Engineers will analyze your requirements and design the best solution for your specific application. Once we design a solution, we will manufacture, do quality control and deliver a high quality display at the best value. To find out more about our Engineered Display Solutions Process, visit our Custom Displays page.

Learn More About Our Custom Displays
