Engineered to Spec
Custom Display Solutions
When a standard display cannot fully support the product, US Micro Products helps define an application-specific solution. We balance performance, integration, sourcing, and cost across TFT, AMOLED, PMOLED, and LCD technologies.
Reliable Source
One team from technology selection through mass production and lifecycle management.
Reliable Product
EVT, DVT, and PVT validation ensures your display meets spec under real-world conditions.
Competitive Price
Designs optimized for manufacturability — best performance at the lowest total cost.
Four Technologies
TFT, AMOLED, PMOLED, and passive LCD — technology-agnostic recommendations based on your needs.
Our Methodology
Engineered Display Solution Process (EDSP)
Our proven three-step methodology takes your project from concept through mass production with full engineering support at every stage.
Technology Selection
Customer inquiry → Explore application options → Technology fit → Verify project choices. We evaluate your requirements against available technologies and confirm a practical approach before moving to design.
- 1.1 Customer inquiry
- 1.2 Explore application options
- 1.3 Technology fit
- 1.4 Verify project choices — Technology Confirmation
Design
Feasibility study → Implement design → Order samples. Our engineers execute the complete display design — panel specification, cover glass, touch, bonding, FPC routing — and deliver working prototypes for your evaluation.
- 2.1 Feasibility study
- 2.2 Implement design
- 2.3 Order samples
Manufacturing
EVT → DVT → PVT → Mass production. Every custom display goes through Engineering, Design, and Production Validation before reaching your production line.
- 3.1 EVT: Engineering Validation Test
- 3.2 DVT: Design Validation Test
- 3.3 PVT and customer approval: Production Validation Test
- 3.4 Mass production
Customization Options
What We Customize
Every display in our catalog can serve as a starting point. We adapt the relevant features to meet the application requirements.
Size & Shape
Custom diagonal sizes, round, rectangular, notched, cutout
Brightness
Standard (250 nits) to sunlight-readable (2,500+ nits)
Optical Bonding
Air gap elimination for contrast, readability, shock resistance
Cover Glass
Chemically strengthened, AR/AG/AF coatings, custom printing
Interface
SPI, I2C, RGB, LVDS, MIPI DSI, eDP — matching your system
Touch
PCAP with glove mode, wet-finger, water rejection
Temperature
-40°C to +85°C with heater circuits and wide-temp backlights
FPC & Connector
Custom flex cable length, routing, connector type, pin assignment
Backlight
Custom LED color, brightness, uniformity, dimming range
EMI Shielding
Conductive coatings, mesh, gaskets for medical and military
Protective
Conformal coating, potting, ruggedization for harsh environments
By Technology
Custom Display Technologies
Each display technology offers distinct customization options. Explore what may fit your application.
Custom TFT Displays
The broadest customization platform. Modify size, brightness, interface, cover glass, bonding, and environmental rating across our 225+ TFT display portfolio.
Sizes
1.22" – 8.5"
Resolution
128×128 to QHD
Structures
COG, TAB, COF
Interfaces
RGB, TTL, LVDS, MIPI
Customization Areas
Panel
LC type (TN/VA/IPS), dimension, color gamut, polarizer, shape, heater, sunlight readable, FPC
Backlight
LED position (array/edge), outline dimension, mounting hole, brightness/uniformity, lifetime
Cover
Plastic or glass, AR/AG/HC treatment, thickness, hardness, shape, drill hole, mask printing
Bezel
Metal or plastic frame, screw hole, output port location, bezel size
Touch
RTP/CTP, GG/GFF/GF/DITO/SITO/on-cell/in-cell, single/multi/gesture
Others
Air/optical/nano bonding, OCA/OCR, PCBA, interface bridge, LED driving, AD board (DVI/VGA/DP/USB)
Custom AMOLED Displays
Custom AMOLED solutions for wearables, medical, and premium consumer. Round, rectangular, and flexible form factors with custom cover glass, touch, and bonding.
Sizes
0.39" – 6"
Resolution
Up to 3840×2160 UHD
Structures
Soldering, ACF bonding, Connector
Interfaces
Customizable
Customization Areas
Panel
Dimension, color gamut, polarizer, shape (round/rect/square), heater, sunlight readable, FPC
Cover
Plastic or glass, AR/AG/HC treatment, thickness, shape, drill hole, mask printing (logo/icon/color)
Bezel
Metal or plastic frame, screw hole location, output port, bezel size
Touch
GG/GFF/GF/DITO/SITO/on-cell/in-cell, single/multi/gesture, I2C/USB
Bonding
Air/optical/nano bonding, OCA/OCR
Others
PCBA, interface bridge (8080/SPI/I2C), DCDC
Custom PMOLED Displays
Ultra-low-power custom OLED solutions for compact wearable and instrumentation applications. Custom shapes, colors, and interface configurations.
Sizes
0.5" – 5.9"
Resolution
Up to 256×64 or 160×128
Structures
COG, COF, TAB
Interfaces
8080, SPI, I2C
Customization Areas
Panel
Resolution, dimension (OD/VA/AA/thickness), monochrome or full color, contrast 2000:1, viewing 160°, shape, heater, FPC
Cover
Plastic or glass, AR/AG/HC treatment, thickness, hardness, transmittance, shape, drill hole, mask printing
Bezel
Metal or plastic frame, screw hole, output port location, bezel size
Touch
RTP/CTP, GG/GFF/GF/DITO/SITO/on-cell/in-cell, single/multi/gesture
Bonding
Air/optical/nano bonding, OCA/OCR
Others
PCBA, interface bridge (8080/SPI/I2C), DCDC
Custom Passive LCD
Custom character and graphic LCD solutions with modified dimensions, backlights, temperature ranges, and connector configurations. Low cost, ideal for small applications.
Sizes
Up to 5–6"
Resolution
Up to 320×240
Structures
COB, COG, TAB, COF, SMT
Interfaces
6800, 8080, SPI, I2C
Customization Areas
Panel
LC type (TN/STN/FSTN/VATN), image, monochrome/full color, background color, reflective/transflective/transmissive, shape, heater, FPC
Backlight
Backlight color, outline dimension, mounting hole, brightness/uniformity, lifetime
Cover
Plastic or glass, AR/AG/HC treatment, thickness, shape, drill hole, mask printing
Bezel
Metal or plastic frame, screw hole, output port location, bezel size
Touch
RTP/CTP, GG/GFF/GF/DITO/SITO/on-cell/in-cell, single/multi/gesture
Others
Air/optical/nano bonding, OCA/OCR, PCBA, interface bridge, LED driving, DCDC
Why Choose US Micro Products for Custom Displays?
Whether you have detailed specifications or are still defining the requirements, our display engineers can guide the process and help identify a solution that balances performance, manufacturability, and value.
Reliable Source
We manage the full custom display lifecycle — from design through mass production, quality control, inventory management, and EOL transitions. You work with one team from start to finish.
Reliable Product
Every custom display goes through our EVT, DVT, and PVT validation process. We confirm the design against your specifications and operating conditions before supporting production.
Competitive Price
Our engineering team optimizes display designs for manufacturability, performance, and total cost — including integration complexity, lifecycle support, and field reliability.
Frequently Asked Questions
Ready to Start Your Custom Display Project?
Share your optical, mechanical, electrical, environmental, and sourcing requirements, and our engineers will help define the right path forward.
