Passive LCD
Custom Passive LCD Displays
A passive LCD is a low cost option when a display is needed for an application that doesn't require a high performance display. The difference between a passive-matrix and an active-matrix LCD is that the passive matrix has a grid of horizontal and vertical wires and at the intersection there is an LCD element that makes a single pixel. The active-matrix LCD has a transistor on each pixel, which allows for more contrast, higher resolution and faster response time.
Size Range
As big as 5~6"
Max Resolution
320x240
LC Types
TN, STN, FSTN, VATN
Structures
COB, COG, TAB, COF, SMT
Interfaces
6800, 8080, SPI, I2C
Display Mode
Reflective, Transflective, Transmissive
Advantages
When Should You Consider Creating a Custom Display?
Your new design requires application-specific changes that justify moving beyond a standard display
You already have a design and need a display that matches your design
Many projects begin with a standard off-the-shelf product and then move to targeted changes once application requirements are clear.
Customizations We Offer
Panel
As big as 5~6"
320x240
COB, COG, TAB, COF, SMT
OD, VA, AA, thickness — customizable
TN, STN, FSTN, VATN
Customizable
Monochrome, full color, color gamut, color coordinate, background color
Reflective, transflective, or transmissive
Customizable
Customizable
Customizable
6800, 8080, SPI, I2C
Customizable
Customizable
Criteria specified by customer
Criteria specified by customer
Round, rectangle, square, multiple cut shapes
Available for low temperature operation
High brightness options
Change FPC shape, add double-side tape, other customizations
Backlight
Customizable
Customizable
Customizable
Customizable
Customizable
Cover
Custom printing options
Plastic or glass
AR, AG, HC coatings
Custom thickness, hardness, transmittance
Custom shapes, drill holes
Black mask, logo, icon, color
Bezel
Metal or plastic
Customizable
Customizable
Customizable
Touch
RTP (Resistive) or CTP (Capacitive)
GG, GFF, GF, DITO, SITO, On-cell, In-cell
Single, multi, or gesture
Customizable
Others
Air, optical, or nano bonding (OCA/OCR)
Interface bridge, LED driving, DC-DC
Why Choose US Micro Products?
Reliable Source
End-to-end passive LCD management. One team from design through mass production and lifecycle support.
Reliable Product
EVT, DVT, and PVT validation for high-volume applications.
Competitive Price
Passive LCD is a cost-effective display technology, and targeted modifications can often be evaluated without materially changing the value profile.
Frequently Asked Questions
What is the difference between passive LCD and TFT?
A passive LCD has a grid of wires with an LCD element at each intersection. A TFT (active matrix) has a transistor on each pixel, allowing more contrast, higher resolution, and faster response time. Passive LCDs are lower cost and ideal for simpler display needs.
What LC types are available?
TN (Twisted Nematic), STN (Super Twisted Nematic), FSTN (Film-compensated STN), and VATN (Vertical Alignment TN). Each offers different contrast, viewing angle, and cost characteristics.
What shapes are available?
Round, rectangle, square, and multiple cut shapes. Passive LCD glass can be cut to a wide variety of custom shapes.
All custom displays follow our Engineered Display Solution Process (EDSP) — from technology selection through EVT, DVT, PVT, and mass production.
Ready to Start Your Custom Project?
Our display engineers can guide the customization process and help identify a solution that fits your product, sourcing needs, and production path.
Request a Quote
