Full Color TFT LCD Displays
Custom TFT Displays
TFT stands for Thin Film Transistor, an LCD flat-panel architecture in which each pixel is controlled by one or more transistors. TFT screens are also known as active-matrix LCDs, in contrast to passive-matrix LCDs, which are direct-driven with a limited number of segments. The transistor layer occupies only a small portion of each pixel area, allowing light to pass through the display structure.
Size Range
1.22" ~ 8.5"
Resolution
128x128 to QHD
LC Types
TN, VA, IPS
Structures
COG, TAB, COF
Interfaces
RGB, TTL, LVDS, MIPI, MDDI, V-by-one
Backlight
Array or edge LED
Advantages
When Should You Consider Creating a Custom Display?
Your new design requires application-specific changes that justify moving beyond a standard display
You already have a design and need a display that matches your design
Many projects begin with a standard off-the-shelf product and then move to targeted changes once application requirements are clear.
Customizations We Offer
Panel
1.22" ~ 8.5"
128x128 to QHD
COG, TAB, COF
OD, VA, AA, thickness — customizable
TN, VA, IPS
TN is positive, IPS / VA is negative
Monochrome or full color
NTSC percentage, color standard, color coordinate, reflective / transflective / transmissive
Optional — contrast ratio, viewing angle, temperature range
RGB, TTL, LVDS, MIPI, MDDI, V-by-one
Soldering, ACF bonding, Connector
Customizable
Criteria specified by customer
Criteria specified by customer
Round, rectangle, square
Available for low temperature operation
High brightness options
Change shape, add double-side tape, other customizations
AR, AG, HC
Backlight
Array or edge
Customizable
Customizable
Customizable
Customizable
Cover
Custom printing options
Plastic or glass
AR, AG, HC coatings
Custom thickness, hardness, transmittance
Custom shapes, drill holes
Black mask, logo, icon, color
Bezel
Metal or plastic
Customizable
Customizable
Customizable
Touch
RTP (Resistive) or CTP (Capacitive)
GG (glass on glass), GFF, GF, DITO, SITO, On-cell, In-cell
Single, multi, or gesture
Customizable
I2C, USB
Others
Air, optical, or nano bonding (OCA/OCR)
Interface bridge, LED driving, DC-DC
DVI, VGA, VA, DP, S-video, USB
Why Choose US Micro Products?
Reliable Source
End-to-end custom TFT management. One team from design through mass production and lifecycle support.
Reliable Product
EVT, DVT, and PVT validation on every custom TFT design. We don't ship until it meets spec.
Competitive Price
The broadest TFT portfolio means more starting points. Less custom work, lower cost, faster delivery.
Frequently Asked Questions
What are the advantages of TFT displays?
Good display quality, high brightness, competitive cost, and multiple customizations available. TFT is the most versatile display technology for a wide range of applications.
What LC types are available?
TN (Twisted Nematic), VA (Vertical Alignment), and IPS (In-Plane Switching). TN is positive image, IPS and VA are negative. Each offers different viewing angle, contrast, and cost characteristics.
What interfaces are supported?
RGB, TTL, LVDS, MIPI, MDDI, and V-by-one. Custom connector types (soldering, ACF bonding, connector) and PIN assignments available.
Can you add an AD board?
Yes. We integrate AD boards with DVI, VGA, VA, DP, S-video, and USB input for applications that need standard video input conversion.
All custom displays follow our Engineered Display Solution Process (EDSP) — from technology selection through EVT, DVT, PVT, and mass production.
Ready to Start Your Custom Project?
Our display engineers can guide the customization process and help identify a solution that fits your product, sourcing needs, and production path.
Request a Quote
