AMOLED Displays
Browse 77+ AMOLED display modules from 0.95" to 27". True blacks, ultra-thin profile, energy efficient. Ideal for wearables, medical, military & industrial. Request specs today.
AMOLED Display Modules
US Micro Products stocks over 77 AMOLED display modules from 0.95" to 27", serving OEMs across the wearable, medical, military, industrial, consumer, gaming, automotive, aerospace, and kiosk markets.
AMOLED Benefits
Excellent Viewing Angles
AMOLED panels maintain consistent color and brightness at extreme off-axis positions, ensuring reliable visual performance regardless of viewing angle — critical for multi-operator environments and wearable devices viewed on the move.
High Contrast
Contrast ratios far exceeding LCD technology deliver crisp, readable text and graphics in any lighting condition. For procurement, this means fewer field complaints and higher end-user satisfaction with the finished product.
True Blacks
When the color black is depicted, the pixel is absent of light rather than illuminated. Designing a GUI with black backgrounds optimizes energy consumption — a direct cost advantage for battery-powered products.
Energy Efficient
AMOLED requires no backlight like its LCD counterpart, which consumes the majority of display energy. This translates to longer battery life, smaller batteries, and reduced total cost of ownership for portable products.
Narrow Bezel
The bezel — space between active area and outside dimension — is smaller on AMOLED than alternative displays of similar size. This enables more compact product designs and higher screen-to-body ratios.
Thinner Profile
No backlight allows for a slimmer display stack, freeing up space for a larger battery, reducing device weight, and allowing extra room for other components — simplifying mechanical design and sourcing.
Ideal for Portable & Wearable
The wearable, consumer, military, and medical industries are driving towards lighter, thinner, and sleeker products. AMOLED delivers the form factor advantages these markets demand with the quality and availability procurement requires.
Product Catalog
Showing 1–20 of 77 products
| Size | Part Number | Resolution | Brightness | Contrast | Temperature | Viewing Angles | Actions |
|---|---|---|---|---|---|---|---|
| 0.95" | USMP-A010-012024UGB-A0 | 120 x 240 | 450 cd/m2 | 100,000:1 | -20°C ~ 70°C | 80 / 80 / 80 / 80 | |
| 1" | USMP-A010-018027UGB-A0 | 184 x 276 | 350 cd/m2 | 1,000,000:1 | -20°C ~ 70°C | 80 / 80 / 80 / 80 | |
| 1.04" | USMP-A010-034034UGB-A0 | 340 x 340 | 630 cd/m2 | 100,000:1 | -20°C ~ 70°C | 80 / 80 / 80 / 80 | |
| 1.106" | USMP-A011-036036UGB-A0 | 360 x 360 | 360 cd/m2 | 100,000:1 | -20°C ~ 70°C | 80 / 80 / 80 / 80 | |
| 1.32" | USMP-A013-046046CGB-A0 | 466 x 466 | 450 cd/m2 | 100,000:1 | -20°C ~ 70°C | 85 / 85 / 85 / 85 | |
| 1.32" | USMP-A013-046046UGB-A0 | 466 x 466 | 600 cd/m2 | 1,000,000:1 | -20°C ~ 70°C | 80 / 80 / 80 / 80 | |
| 1.38" | USMP-A014-012040UGB-A0 | 128 x 400 | 600 cd/m2 | 1,000,000:1 | -20°C ~ 70°C | 80 / 80 / 80 / 80 | |
| 1.39" | USMP-A014-045045CEB-A0 | 454 x 454 | 350 cd/m2 | 100,000:1 | -20°C ~ 70°C | 85 / 85 / 85 / 85 | |
| 1.39" | USMP-A014-045045NEI-A0 | 454 x 454 | 450 cd/m2 | 100,000:1 | -20°C ~ 60°C | 85 / 85 / 85 / 85 | |
| 1.43" | USMP-A014-046046CGB-A0 | 466 x 466 | 450 cd/m2 | 100,000:1 | -20°C ~ 70°C | 85 / 85 / 85 / 85 | |
| 1.46" | USMP-A015-019036UGB-A0 | 194 x 368 | 450 cd/m2 | 100,000:1 | -20°C ~ 70°C | 80 / 80 / 80 / 80 | |
| 1.47" | USMP-A015-019036UGB-B0 | 194 x 368 | 600 cd/m2 | 1,000,000:1 | -20°C ~ 70°C | 80 / 80 / 80 / 80 | |
| 1.504" | USMP-A015-046046CGB-A0 | 466 x 466 | 600 cd/m2 | 100,000:1 | -20°C ~ 70°C | 80 / 80 / 80 / 80 | |
| 1.48" | USMP-A015-048048UGB-A0 | 480 x 480 | 600 cd/m2 | 100,000:1 | -20°C ~ 70°C | 80 / 80 / 80 / 80 | |
| 1.62" | USMP-A016-019049UGB-A0 | 192 x 490 | 600 cd/m2 | 1,000,000:1 | -20°C ~ 70°C | 85 / 85 / 85 / 85 | |
| 1.58" | USMP-A016-022046CGB-A0 | 228 x 460 | 450 cd/m2 | 100,000:1 | -20°C ~ 70°C | 80 / 80 / 80 / 80 | |
| 1.576" | USMP-A016-025040UGB-A0 | 256 x 402 | 600 cd/m2 | 1,000,000:1 | -20°C ~ 70°C | 85 / 85 / 85 / 85 | |
| 1.64" | USMP-A016-028045CGB-A0 | 280 x 456 | 450 cd/m2 | 100,000:1 | -20°C ~ 70°C | 85 / 85 / 85 / 85 | |
| 1.6" | USMP-A016-032036CGB-A0 | 320 x 360 | 600 cd/m2 | 100,000:1 | -20°C ~ 70°C | 80 / 80 / 80 / 80 | |
| 1.74" | USMP-A017-033048CGB-A0 | 336 x 480 | 600 cd/m2 | 100,000:1 | -20°C ~ 70°C | 80 / 80 / 80 / 80 |
77 of 77 products match your filters. Request a custom configuration
Custom Engineering
Customization Options
Cover glass
Chemically strengthened, sapphire, curved 2.5D/3D, AR coating, anti-fingerprint
Touch integration
On-cell or external PCAP touch sensors
Optical bonding
Full lamination for shock resistance and outdoor readability
FPC and connector
Custom flex cable routing, ZIF connector selection
Custom shape and size
Round, rectangular, notched, or cutout configurations
Our engineers will evaluate your requirements and recommend the optimal configuration.
Applications
Wearables
Smartwatches, fitness trackers, smart bands
Learn moreMedical
Portable patient monitors, pulse oximeters, handheld diagnostic devices
Learn moreGaming
Handheld gaming devices, VR/AR headsets
Learn moreMilitary
Heads-up displays, wrist-mounted tactical computers
Learn moreIndustrial
Portable HMI, rugged handheld terminals
Learn moreConsumer
Premium IoT devices, smart home controllers
Learn moreKiosk
Interactive kiosks, point-of-sale terminals
Learn moreAutomotive
Dashboard clusters, center console displays
Learn moreAerospace
Cockpit instruments, portable flight equipment
Learn more
Engineering and Supply Chain Solutions for AMOLED Displays
Custom optical bonding, touch integration, and EOL replacement support AMOLED programs from prototype through production:
Custom Display Engineering
Our EDSP process tailors AMOLED display choices around optical, mechanical, and electrical requirements.
Learn more
Display Integration
Optical bonding, custom housing, and full lamination for turnkey AMOLED solutions.
Learn more
Supply Chain Management
Inventory management and logistics ensuring stable availability and competitive lead times for AMOLED modules.
Learn more
Touch Screen Integration
On-cell and external PCAP touch integration for interactive AMOLED applications.
Learn more
EOL Display Replacement
Cross-reference and redesign when your current AMOLED display reaches end of life.
Learn moreWhy Choose Us
Why Choose US Micro Products for AMOLED
Decades of display engineering expertise, direct manufacturer partnerships, and a relentless focus on your success.
Breadth of selection
With 77+ standard AMOLED modules from 0.95" to 27", spanning wearable sizes through large-format panels, you start from a strong baseline before any customization.
Engineering support
Our team evaluates your optical, mechanical, electrical, and environmental requirements and recommends the optimal AMOLED panel for your application.
Custom Display Solutions
Every module in our catalog can serve as a starting point for customization around demanding application requirements.
Reliable sourcing
For procurement teams, we deliver what matters: consistent product quality, stable availability, competitive lead times, and long-term price stability.
