Touch Screen Displays
Browse 24+ touch screen panels from 3.5" to 15.6". Projected capacitive, resistive, SAW, infrared. SITO/DITO sensors, G+G structure, 6H hardness. Request specs today.
Touch Screen Technologies
US Micro Products offers 24+ standard touch screen panels from 3.5" to 15.6", with custom touch solutions available from 2.4" to 55". Touch panels can be integrated with US Micro Products TFT and OLED modules to reduce sourcing complexity and simplify production.
Touch Screen Technologies
Projected Capacitive Touch
The current technology of choice for new designs. Uses a grid of transparent ITO traces to detect finger position through cover glass. Multi-touch capable, no moving parts, and excellent durability for medical, industrial, and consumer applications.
Surface Capacitive Touch
Single-touch capacitive technology that detects changes in capacitance at the surface of a coated glass panel. Cost-effective solution for applications requiring a sealed, durable touch interface without multi-touch requirements.
4, 5 and 8 Wire Resistive Touch
Pressure-based touch input activated by pressing two conductive layers together. Works with gloves, stylus, or bare fingers. Widely used in industrial equipment, vending machines, and point-of-sale applications where input flexibility matters.
Surface Acoustic Wave (SAW)
Uses ultrasonic waves across the touch surface to detect input. Offers the highest optical clarity of any touch technology with excellent light transmittance — ideal for applications where display readability is the top priority.
Infrared (IR) Touch
Optical touch detection using an array of IR emitters and receivers around the display perimeter. Supports large-format displays and is not affected by surface contaminants — suited for high-durability and outdoor applications.
Chemically Strengthened Glass
Chemically strengthened glass and low reflective coating are available on some touch screen displays to improve performance and durability. Increases impact resistance and product lifetime for demanding environments.
Product Catalog
Showing 1–20 of 24 products
| Diagonal Size | Part Number | Sensor Type | IC | Interface | Structure | Surface Hardness | Active Area | Outline Dimension | Actions |
|---|---|---|---|---|---|---|---|---|---|
| 3.5" | USMP-TP035UFW-A0 | DITO | ST1633i | I2C | G+G | 6H | 70.86 x 53.34 | 76.90 x 63.90 x 1.85 | |
| 3.5" | USMP-TP035UFW-B0 | SITO | ST1633i | I2C | G+G | 6H | 70.86 x 53.34 | 76.90 x 63.90 x 1.85 | |
| 4.3" | USMP-TP043UFW-A0 | DITO | ST1633i | I2C | G+G | 6H | 95.64 x 54.46 | 104.84 x 66.80 x 1.45 | |
| 4.3" | USMP-TP043UFW-B0 | DITO | ILI2130 | I2C | G+G | 6H | 97.04 x 55.86 | 104.84 x 66.80 x 1.45 | |
| 4.3" | USMP-TP043UFW-C0 | SITO | ST1633i | I2C | G+G | 6H | 98.04 x 56.85 | 104.84 x 66.80 x 1.45 | |
| 5" | USMP-TP050UFW-A0 | DITO | ILI2511 | I2C&USB | G+G | 6H | 109.60 x 66.40 | 120.70 x 75.80 x 2.00 | |
| 5" | USMP-TP050UFW-B0 | DITO | ST1633i | I2C | G+G | 6H | 109.60 x 66.40 | 123.26 x 80.06 x 1.45 | |
| 5" | USMP-TP050UFW-C0 | DITO | ST1633i | I2C | G+G | 6H | 112.88 x 64.83 | 120.30 x 74.43 x 2.00 | |
| 7" | USMP-TP070UFW-A0 | DITO | ST1633i | I2C | G+G | 6H | 155.81 x 87.52 | 184.81 x 116.52 x 2.00 | |
| 7" | USMP-TP070UFW-B0 | DITO | ILI2511 | I2C | G+G | 6H | 153.00 x 92.04 | 165.00 x 104.60 x 1.85 | |
| 7" | USMP-TP070UFW-C0 | SITO | ILI2511 | I2C&USB | G+G | 6H | 154.00 x 93.04 | 165.00 x 104.60 x 2.00 | |
| 7" | USMP-TP070UFW-D0 | DITO | ILI2511 | I2C&USB | G+G | 6H | 156.01 x 87.74 | 164.90 x 100.00 x 1.60 | |
| 7" | USMP-TP070UFW-E0 | SITO | ILI2511 | I2C&USB | G+G | 6H | 156.01 x 87.74 | 164.90 x 100.00 x 1.60 | |
| 7" | USMP-TP070UFW-F0 | DITO | ILI2511 | I2C&USB | G+G | 6H | 153.00 x 92.04 | 165.00 x 104.60 x 1.85 | |
| 8" | USMP-TP080UFW-A0 | DITO | ILI2511 | I2C&USB | G+G | 6H | 164.00 x 123.50 | 180.30 x 142.30 x 2.05 | |
| 8.4" | USMP-TP084UFW-A0 | SITO | ILI2511 | I2C&USB | G+G | 6H | 171.65 x 128.95 | 182.07 x 140.97 x 2.05 | |
| 10.1" | USMP-TP101UFW-A0 | DITO | ILI2511 | I2C&USB | G+G | 6H | 218.56 x 137.20 | 260.00 x 170.00 x 2.05 | |
| 10.1" | USMP-TP101UFW-B0 | DITO | GT928 | I2C | G+G | 6H | 224.72 x 127.28 | 234.60 x 142.50 x 1.65 | |
| 10.1" | USMP-TP101UFW-C0 | DITO | ILI2511 | USB | G+G | 6H | 218.96 x 137.60 | 240.00 x 163.50 x 1.90 | |
| 10.1" | USMP-TP101UFW-D0 | DITO | ILI2511 | I2C&USB | G+G | 6H | 224.72 x 127.28 | 234.60 x 142.50 x 1.65 |
24 of 24 products match your filters. Request a custom configuration
About Our Touch Screens
Our touch screens are highly customizable:
Touch screens can be integrated with US Micro Products TFT and OLED display modules to reduce sourcing complexity and streamline production.
Variety of sizes
Standard panels from 3.5" to 15.6". Custom sizes from 2.4" to 55".
Clear optical quality
High transmittance for excellent display readability.
Elegant border designs
Custom bezel printing and design options.
6H surface hardness
Durable surface across all standard G+G (Glass + Glass) structure panels.
SITO and DITO sensor types
Single ITO (SITO) patterns both X and Y electrodes on the same substrate. Dual ITO (DITO) places X and Y electrodes on opposite sides, eliminating conductive bridges for excellent resolution at lower cost.
I2C and USB interfaces
Standard communication interfaces across the catalog, with select models supporting both I2C and USB.
Applications
Medical
Surgical displays, patient monitors, diagnostic equipment
Learn moreIndustrial
HMI panels, factory automation, CNC controls
Learn moreGaming
Casino terminals, interactive displays, gaming machines
Learn moreMilitary
Rugged field terminals, vehicle-mounted displays
Learn moreConsumer
Mobile devices, tablets, smart home interfaces
Learn moreKiosk and POS
Self-service terminals, ATMs, vending machines, video kiosks
Learn moreAutomotive
Car navigation devices, center stack controls
Learn moreWearables
Smartwatches, fitness trackers, wearable medical devices
Learn moreAerospace
Cockpit displays, portable flight instruments
Learn more
Engineering and Supply Chain Solutions for Touch Screens
From custom sensor design to end-of-life replacement, our solutions support your touch screen integration from prototype through production:
Custom Display Engineering
Custom touch sensor design, cover glass specification, and integration with US Micro Products display modules.
Learn more
Touch Screen Integration
Optical bonding, custom housing, and turnkey touch-display assembly.
Learn more
Display Integration
Pre-bonded touch panel and display combinations for simplified sourcing.
Learn more
Supply Chain Management
Inventory management and logistics ensuring stable availability and competitive lead times.
Learn moreWhy Choose Us
Why Choose US Micro Products for Touch Screens
Decades of display engineering expertise, direct manufacturer partnerships, and a relentless focus on your success.
Five touch technologies
Projected capacitive, surface capacitive, resistive (4/5/8 wire), SAW, and infrared — we offer the right technology for your application requirements.
Standard to fully custom
24+ standard panels in stock, with custom sizes from 2.4" to 55" and customizable sensor ICs, stack-ups, coatings, and cover glass options.
Seamless display integration
Touch panels are designed to integrate with US Micro Products TFT and OLED display modules, reducing supplier count and simplifying procurement.
Reliable sourcing
Consistent product quality, stable availability, competitive lead times, and long-term price stability for your production needs.
